250ml-2Lbottle full-automatic Factory price mineral water bottle filling and sealing machine turnkey project

  • 1 - 9 Sets
    $15,000.00
  • >=10 Sets
    $13,000.00
Power:
3-12KW
Model Number:
XGF 8-8-3(2000BPH) XGF 18-12-6(4000BPH) XGF 18-18-6(6000BPH) XGF 24-24-8(10000BPH) XGF 32-32-10(15000BPH) XGF 40-40-12(18000BPH) XGF 50-50-15(24000BPH) XGF 60-60-15(30000BPH) OEM SERVICE
Shipping:
Support Sea freight · Land freight
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 45 Negotiable
Customization:
Customized logo (Min. Order: 1 Sets)
Graphic customization (Min. Order: 1 Sets)

More

Layout drawing (Min. Order: 1 Sets)
Factory building (Min. Order: 1 Sets)
Technical Team Service (Min. Order: 1 Sets) Less
Report Suspicious Activity
Overview
Quick Details
Type:
Filling Machine
Applicable Industries:
Food & Beverage Factory, Other
After Warranty Service:
Video technical support, Online support, Spare parts, Field maintenance and repair service
Local Service Location:
Russia, Nigeria
Showroom Location:
None
Condition:
New
Application:
Beverage, Food, Other
Packaging Type:
Barrel, Bottles, CANS
Packaging Material:
Plastic, Wood
Automatic Grade:
Automatic
Driven Type:
Electric
Voltage:
According to Customer requests
Place of Origin:
China
Brand Name:
LUYE
Dimension(L*W*H):
By Model
Weight:
By Model
Certification:
ISO/CE/BV
Warranty:
1 YEAR
After-sales Service Provided:
Field installation, commissioning and training, Field maintenance and repair service, Free spare parts, Online support, Video technical support
Key Selling Points:
Competitive Price
Machinery Capacity:
4000BPH, 8000BPH, 12000BPH, 6000BPH, 20000BPH, 16000BPH, 2000BPH, 1000BPH
Filling Material:
Beer, Milk, Water, Oil, Juice
Marketing Type:
New Product 2020
Machinery Test Report:
Provided
Video outgoing-inspection:
Provided
Warranty of core components:
1 YEAR
Core Components:
Motor, Pressure vessel
Supply:
filling machinery detergent
Name:
mineral water bottle design
Bottle type:
PET Plastic Bottle
Material:
SUS304/316(Meet GMP Standard)
Filling volume:
200ml-2000ml
Structure:
Rotary
Filling precision:
within 2mm
Product:
bottle filling machine south africa
Product Keywords:
mineral water filling bottling machine
Product Certification certification
CE Certified.
Valid from 2016-05-24 until 2021-05-23
Supply Ability
Supply Ability:
20 Set/Sets per Month
Packaging & Delivery
Packaging Details
LUYE-XGF Series Water Filling Machine [ Washing Filling Capping 3 in 1 ] Normally use PE film inside, wooden case packaging.
Port
Shanghai,Ningbo,Guangzhou
Picture Example:
package-img
package-img
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 45 To be negotiated
Video Description
Product Description
EQUIPMENT TYPE
FULL AUTOMATIC



APPLICATION FOR BOTTLE:

Round or suqre bottle
Volume 200 - 2000ml
Diameter:Φ50~120mm

Bottle height:160~320mm

 Diameter of bottle mouth:Φ25~38mm
CAPACITY PER HOUR
 3000~36000BPH
GUARANTEE
Free warranty since 12 months after installation & commissioning, or 15 month after delivery date
AFTER SERIVCE
Life-long maintenance


PRODUCT APPLICATION

Full Automatic 3 in 1 Complete PET Bottle Pure Mineral Water Filling Production Machine

This automatic rinsing, filling and capping machine, could be applicable quantitative filling and capping of drinking water,mineral water,Pure water. It has functions as follows: Disinfectant rinse, aseptic water rinsing; automatically i liquid filling tank, inlet material; feed bottles by air conveyer (or screw convey);automatically rinse, open valve and feed caps; not rinse, open valve and feed caps without bottles .
Compact structure; reasonable design and convenient operation and maintenance. Main machine is adopted frequency speed control, it runs stable and credibility. Material of contacted with product we use high food grade stainless steel. After exchanging changeover parts, it is applicable for different kinds of PET bottle filling.
We adopt advanced touch screen operation and realize human-machine communication. Function of control system as follows: product speed control, automatic stop with faults and take count of output,.etc.

PRODUCT ADVANTAGE:

 PLC and Touch screen full automatic control. Easy for operate

 Fastly different bottle size replacement

 Concise structure, reliable and durable, easy to maintain.

Washing part composes of bottle washing clamp, upper rotary plate, guide rail, water distributing plate, shield, water spraying device, water tray etc.

Bottle washing clamp rotates with the upper rotary plate, and open the bottle mouth clamp with elastic distortion when contacting the bottle feeding starwheel, which can clamp the bottle neck, then overturns at 180° along the guide rail, bottle mouth may become downwards for cleaning and drying the bottle with water, then overturn for 180°, bottle mouth becomes upwards and then conveyed with the starwheel; shield can prevent sprinkling of cleaning water; water distributing plate can deliver the cleaning water from the still parts to the rotary parts.

Filling part mainly composes of bottling barrel, bottling valve, guide rail, lifting device, bottle clamping lift device etc.

Bottle is conveyed to the bottling machine with the clamp plate of starwheel drive IV, bottling bottle clamp plate supports the bottle neck and rotates together with the bottling, and ascend along the guide rail and then open the bottling valve for bottling, after finishing bottling, it descend and loose the bottling valve, bottling valve may automatically close. Bottle is discharged from the bottling machine along the clamp plate of starwheel drive V.

Capping part composes of cap separating mechanism, capping machine and cap arranging mechanism.
Bottle is conveyed into the capping machine with 3# starwheel and then is clamped with the bottle clamping block; the cap is arranged by the cap arranging mechanism and then is delivered to the cap separating mechanism from the lower cap tank; cap separating mechanism can separate the caps, and capping head may ascend and remove the cap and press it onto the bottle mouth with cam; under the drive of gear, capping head tighten the cap on the bottle mouth along the shaft, and keep constant capping moment; the well capped bottle is delivered out with 4# starwheel. The capping machine is connected with cap separating mechanism, lower cap tank, cap arranging mechanism with harmonious combination through several movements for delivering bottle, delivering cap, holding cap and capping.

About LUYE Machinery

SINCE 1989

LUYE has More than 30 years Professional Manufacturer of Turn-key Beverage Machinery.
RO WATER TRATMENT SYSTEM
•Stainless steel high pressure film shell •All kinds of capacity indicator, pressure indicator, electricity magnetic valve, balance device and pipe valve system •Online type pressure auto self-protection device •Online type electricity indicator (with stable compensation) •System safe protecting and alarm system •Stainless steel frame
Choose the above equipment according to your Raw water report.
BOTTLE BLOWING MACHINE

Full automatic blow molding machine is suitable for producing PET plastic containers and bottles in all shapes. It is widely used to produce the carbonated bottle, mineral water, pesticide bottle oil bottle cosmetics, wide-mouth bottle and hot fill bottle etc.

Choose the above equipment according to your bottle design and PET preforms.






LABELING MACHINE
Optional Equipment :
1)Heat shrink sleeve labeling machine
2)OPP Hot gule melt labeling machine
3)Self-adhesive labeling machine

Choose the above equipment according to your bottle design and label material.




PE FILM SHRINK WRAPPING PACKAGE MACHINE
Optional Equipment :
1)PE film shrink wrapping package machine
2)Half-Tray carton Shrink wrapping package machine
3)Carton package machine

Choose the above equipment according to your requirment and Packing materils.
Certifications
Related Products

Juice factory and bottle juice machine




PE Film Bottle Heat Shrink Packaging Machine




5 Gallon Filling Machine




Our Service

INSTALLATION SERVICE

When you finish the Preparation conditions,our fast and professional aftersales service engineer team will go to your factory to install the machine,give you the operating manual,and train your employee until they can operate the machine well.



THE SAMPLE SERVICE

1.We can send you the video of the running machine.

2.You are welcome to come to visit our factory,and see the machine running.



CUSTOMIZED SERVICE

1.We can design the machines according your requirements(materil,power,filling type,the kinds of the bottles,and so on),at the same time we will give you our professional suggestion,as you know,we have been in this industry for many years.



AFTER-SALES SERVICE

1.We will delivery the machine and provide the bill of load on time to make sure you can get the machine quickly

2.When you finish the Preparation conditions,our fast and professional aftersales service engineer team will go to your factory to install the machine,give you the operating manual,and train your employee until they can operate the machine well.

3. We often ask feedback and offer help to our customer whose machine have been used in their factory for some time.

4.We provide one year warranty

5.Well-trained & experienced staff are to answer all your inquiries in English and Chinese

6 .24 hours for engineer response (all services part 5days in customer hand by Intl' courier).

7 .12 Months guarantee and life-long technical support.

8.Your business relationship with us will be confidential to any third party.

9. Good after-sale service offered, please get back to us if you got any questions.



QUALITY CONTROL

We have the single quality department,that make sure the material of the raw materials is  good,and ensure the machine running smoothly.


If you want to know more information about the product,You can send an inquiry, we will solve any of your problems and send you running vedio.

Customer Feedback
FAQ

1.ARE YOU MANUFACTURER OR TRADE COMPANY?

We are manufacturer, located in Zhangjiagang. We are Specialized in beverage machinery 30 years!Our company business is supply all kind of beverage filling machine , package machine, water treatment machine And complete line from A-Z for water, juice , carbonated drink, beer, Aluminum Can drink , all kind of bottle drink filling machine

2.WHAT'S THE ORDER PROCESS?

a.Inquiry-- Provide us all your clear requirements.

b.Quotation-- Official quotation form with all clear specifications.

c.Payment terms-- T/T 30% in advanced, balanced before shipment. We can talk about this when deal.

d.Shipping-- By sea, Detailed picture of package will be provided.

3.CAN YOU GIVE ME YOUR PRICE LIST?

Sorry, we are machine manufacturer, we have more than 100 items, and each machine have different bottle Type ,weight, Voltage, Dimension, Capacity, Usage so on request. So please send me your detail request, then I will email you back the price.

4.WILL YOU HAVE SOME DISCOUNT?

a.To clients who bring repeat orders and large orders

b.Please contact us for Better Quote.

5.HOW CAN I INSTALL MY MACHINE WHEN IT ARRIVES?

We will send our engineer to go to buyer's factory to install, test machines, and train buyer's staff how to operate, maintain machines.
